Jungle – LED G6 630W
The Jungle advanced LED system was designed to be efficient and easy-to-install right out of the box. With a variety of power cord length options, whether you are looking to mount the LED driver on the side of a rack or on the fixture itself, Jungle G6/630W comes with simple snap-lock connectors that make reconnecting cables quick and swift. The Jungle LED system retains an IP65 wet-location rating along with its corrosion resistance build will accommodate installation in your grow space with minimal limitations.
Full Cycle Spectrum
External Control Connectivity
Corrosion Resistance
Surge Protection
Detachable Power Supply/LED Driver (Multiple Remote Mounting Option)
Energy Efficient (Uses 40% less energy than HPS lamps)
Certification: ETL, UL 1598 Wet-Location, IP65 & CE
Warranty: 3-Year Standard, 5-Year Limited
Jungle LED G6/630 offers high-performance light solution, delivering a full-cycle spectrum for vegetative growth and bloom stages to cede a more robust yield.
The power of advanced indoor LED for complete plant growth and rapid development.
Detachable Power Supply (LED Driver)
The detachable design of Jungle G6’s power supply (LED driver) provides the flexibility of remote mounting onto most vertical rack systems without adding attachments or modification to your existing space. With the detachable power supply (LED driver), growers have the option to install the power unit away from growing space with its wall-mount ready capability.
Heat Dissipation – Removes unwanted heat from your grow space when power supply is mounted away from fixture
Versatility – Full spectrum to illuminate grow tables/trays on vertical racks with uniformity
Maximize Grow Space – Ultra-low profile increases stackability on multi-tier racking, ideal for vertical application
Technical Specifications:
Item No.: JN-LED/G6
Input Power: 630W
Input Voltage: 100-277V or 208-480V
PPF: 1700 µmol/s
LED Efficacy: up to 2.7 µmol/j
Rated Lifetime: 50,000 hours
Certification: ETL, UL1598 Wet-location, IP65 & CE
Dimension: 47.5 x 42.8 x 4.4 (in) | 1206 x 1087 x 112 (mm)
Weight: 20 lbs / 9.1 kg | 34.0 lbs / 15.4 kg (including driver)
ETL
Max Amperage by Voltage Service (100-277V)
Voltage 120V 208V 240V 277V
Amperage 5.25A 3.03A 2.63A 2.27A
Max Amperage by Voltage Service (208-480V)
Voltage 208V 240V 277V 340V 480V
Amperage 3.05A 2.63 2.30A 1.92A 1.38A
Jungle LED J1 spectrum
Jungle LED J2 spectrum
